Seco-Larm SA-025Q Timer

Seco-Larm ITEM: SA-025Q
Seco-Larm SA-025Q Timer
Seco-Larm SA-025Q Timer

Seco-Larm SA-025Q Timer

Seco-Larm ITEM: SA-025Q
Regular price $23.73
/
  • Free shipping on most items over $200
  • We have 15+ years of industry experience
  • GSA, Net 30 and purchase orders available
Shipping calculated at checkout.

Description

Seco-Larm SA-025Q Timer

The SA-025Q Programmable Timer Module is suitable for a wide range of timed security and access control operations. Auto-sensing of input voltage and DIP switches for programming make installation easy.

  • Timer can be set from 1 second to 60 minutes
  • Can be triggered via an N.O. positive (+) trigger input signal or an N.C. negative (-) trigger device or by powering up the unit
  • Relay can be programmed to activate at the start or at the end of the timing cycle
  • Relay can also be set to activate for one second at the end of the timing cycle
  • Relay can be programmed to pulse (flash) or be steady on
  • Built-in reset function to manually reset timing cycle
  • Form-C relay, contact rated 10A@24VDC/250VAC
  • LED indicates relay is energized
  • 12~24VDC operation (auto sensing)
  • Current draw – Less than 1mA (standby) or 40mA (relay energized)
  • Functions programmed via DIP switches – no jumpers to cut
