Description

Seco-Larm SEA SK-1123-SDQ 1100 Code Keypad

The Seco-Larm SEA SK-1123-SDQ Keypad allows for 1,100 users over 2 outputs with codes being 4~8 digits. Output #1 is a Form C relay that runs at 1A@30VDC and can hold 1,000 users while output #2 is also a Form C relay that runs at 1A@30VDC but only holds 100 users. The outputs can be programmed to activate for up to 99,999 seconds (nearly 28 hours). There are super user codes that give admins access to keypad. It is also able to have up to 50 (01~50) possible temporary visitor codes, which can be programmed for one-time or limited-time use (1~99 hours). It can have up to 50 (01~50) duress/egress codes for output #1 and 10 (01~10) for output #2 that signals a silent alarm if an authorized user is forced to open the door under duress. It can also have an optional warning alarm and delayed egress. It includes a Real-time clock to auto-disable access at specific times. Comes with a mantrap function for a protected area with two doors, this feature allows only one door to be open at a time. All of this is programmed directly from the keypad: No need for an external programmer. The keypad illuminates when a button is pressed and the backlight can be programmed for FULL, AUTO, or OFF in standby mode. The Seco-Larm SEA SK-1123-SDQ Keypad is IP66 Weatherproof Rated and has a durable and attractive stainless steel faceplate. It can run on 12~24 VDC/VAC with auto-adjusting operation and has a tamper output with N.C. Dry contact that runs at 50mA@24VDC max. It mounts to a standard single-gang back box (surface-mount back box included). It has a door sensor input for anti-tailgating operation, door-propped-open warning, and door-forced-open warning. EEPROM Memory protects programmed information in case of power loss
