Description

Series Loop Detector

The Model BX-LP is a single channel, low power vehicle detector with two relay outputs.



  • External DIP Switches
  • Constructed Of High Temperature Rated Plastic
  • Four Loop Frequencies Selectable From Front Panel
  • Fail LED Indicates Current Loop Failure Or Loop Failures
  • Eight Levels Of Sensitivity Selectable From PCB Mounted DIP Switches
  • Selectable Fail-Safe or Fail-Secure Operation During Loop Failure Conditions
  • Sensitivity Boost For Applications Where High-Bed Vehicles Might Be Encountered
  • Detect Memory Feature Maintains Detection During Momentary Power Interruptions Of Up To Two Seconds
  • Pulse-on-Exit
  • Pulse-on-Entry
  • 12V DC Input Power, Relay Outputs
  • 11-Pin Amphenol Style Male Connector
  • Delay Outputs A & B For Two Seconds
  • Operating Temperature: -30°F To 180°F
  • Dimensions: 3" (H) x 1.75" (W) x 4.3" (D) (Excluding Connector)
  • Dual Outputs: Output A - Limited Presence, True Presence TM, Output B: Presence (Duplicates Output A)
  • Printed Circuit Boards Made From 0.062" Thick FR4 Material With 2 oz. Copper On Both Sides and Plated Through Holes With Polyurethane Coating
