BEA 10MAGLOCK1ULDS 1200lb Maglock, Single w/ Door Status Sensor

BEA ITEM: 10MAGLOCK1ULDS
BEA 10MAGLOCK1ULDS 1200lb Maglock, Single w/ Door Status Sensor
BEA 10MAGLOCK1ULDS 1200lb Maglock, Single w/ Door Status Sensor

BEA 10MAGLOCK1ULDS 1200lb Maglock, Single w/ Door Status Sensor

BEA ITEM: 10MAGLOCK1ULDS
Regular price $272.00
/
  • Free shipping on most items over $200
  • We have 15+ years of industry experience
  • GSA, Net 30 and purchase orders available
Shipping calculated at checkout.

Description

BEA’s 1,200 LB MAGLOCKS WITH DS provide a standards compliant solution as part of an access control system for retail, healthcare, financial, education or storage facilities. The 1,200 lb holding force is ideal for mid- to high-level traffic in commercial buildings. The door status sensor can be used to monitor the door position, eliminating the need for a separate door switch.  BEA’s electromagnetic locks provide reliability and durability in areas for authorized individuals or doorways leading to an emergency exit.  Common applications include access control or egress doors using a sensor or a switch to release the locking device.

The 1,200 LB MAGLOCKS WITH DS can be used on hollow metal, wood, aluminum, glass and composite door materials and are available in surface mount single or double door configurations. Additionally, the adjustable zero to 90 second relock time delay and the lock (bond) status sensor allow configuration of the settings as needed.

  • User-Configurable

  • Enhanced Access Control / Monitoring

  • UL 294 Listed Models Available

  • Anti-Tampering

Can I use a transformer and a rectifier to power a MAGLOCK?

No. UL MAGLOCKS must be powered from a UL-listed, regulated, power-limited, power supply.

I have an all-glass, swing door. How do I mount the armature plate?

Use the U-Bracket (10UBRACKETUL) to mount the armature to the swing door.

How do I mount a MAGLOCK to be used on the pull side of a swing door?

Use the L and Z bracket kit: 600lb single = 10LZBRMAG3UL 1200lb single = 10LZBRMAG1UL 600lb double = 10MAG6LZUL 1200lb double = 10MAG5LZUL

Why is the lock not releasing after I connect my Push-to-Exit switch to the COM. and N.O. terminals on the terminal strip?

That is a Lock Status relay that switches state when the bond occurs; not a lock release.

Why will the MAGLOCK not bond to the armature even though the red LED is on?

Verify that your power supply has sufficient amperage. Verify that you have the correct power supply; it must be a UL-listed, regulated, power-limited, power supply.

Why is the bond between the MAGLOCK and the armature plate weak?

Verify the amperage. If the power is good, remove the spring-loaded button attached to armature plate. Verify that the armature plate is properly aligned with the MAGLOCK body.

Can I replace only the board of the MAGLOCK body?

No. The entire MAGLOCK assembly must be replaced.

What is the default voltage for the jumpers?

24 VDC

Why won’t the LED turn Green?

1. The armature plate is too tight on door. 2. The armature plate is out of alignment. 3. The wrong power supply is being used.

What does the potentiometer do?

For setting a re-locking delay (up to 90 seconds) when using a momentary switch to release the lock.
