DoorKing 1520 and 1524 Card Readers Manuals & Support

The DoorKing 1520 and 1524 are stand-alone card readers for one door or gate. Memory holds 1,000 cards, and the relay output runs an electric strike or magnetic lock.

A free exit input takes an exit button, and a 26-bit Wiegand input adds a second reader. Programming uses control cards or an IR remote, and a 12 VDC supply is included.

Identify your model

The 1524-331 is the card reader only. The 1524-080 adds a lighted enclosure. The 1520 is the single door controller version.

Key specs

Cards	Up to 1,000 (DK Prox)
Output	Relay for strike or maglock
Inputs	Free exit, 26-bit Wiegand
Programming	Control cards or IR remote
Power	12 VDC supply included

Manuals and documents

Troubleshooting

Card not accepted

Check that the card was added with the control card or IR remote.
Check the card type matches the reader.

Damage over time

Do not mount the reader on a moving gate or next to a slamming gate panel.

Common questions

Up to 1,000 DK Prox cards.

Yes. A 26-bit Wiegand input takes a second reader.

DoorKing calls for at least 10 ft from the gate and operator when the reader opens a vehicle gate.
