Seco-Larm SM-4303-TQ/W Roller-Ball Recessed Mount Magnetic Contact - White
Seco-Larm SM-4303-TQ/W Roller-Ball Recessed Mount Magnetic Contact - White
- Current Trade Policy Costs Included In Price
- In Cart Discounts Offered on Many Products
- GSA, Net 30 and purchase orders available
Description
The Seco-Larm SM-4303-TQ/W is a rollerball-type recessed-mount contact for closed-loop circuits. The magnet and reed switch are both inside one white ABS housing, with a 360° rollerball, 1/4 in (6 mm) of travel and screw terminals.
The rollerball is pressed in when the door or window closes, so no separate magnet goes on the door. The SPST reed switch has ruthenium on gold under-plating, rated 0.1 A at 100 VDC (max), and 50 million cycles. Size is 25/32 x 3/4 x 1/4 in (19.8 x 19 x 6.3 mm). Operating range is -15 to 160 °F. Lifetime limited warranty.
What's Included
- Contact switch
- Spacer
- Mounting screws
Before You Order
- Sold individually (each).
- Wires to a closed-loop zone on an alarm panel or a door-sensor input on an access controller.
- Mount the switch in the frame where the door or sash presses the rollerball in. Use the spacer if the closed gap is too wide.
- For pre-wired 18 in leads, see the SM-4302-LQ/W. For a plain plunger, see the SM-4301-TQ/W.
