2BX Open/Close Exterior Control Station (Metal)
2BX Open/Close Exterior Control Station (Metal)
- Current Trade Policy Costs Included In Price
- In Cart Discounts Offered on Many Products
- GSA, Net 30 and purchase orders available
Description
The 2BX is a 2-button Open / Close control station in a die-cast aluminum enclosure rated NEMA 3R, 4 and 12. It surface mounts outdoors on a wall, post or column. Buttons are momentary, normally open contacts. The enclosure measures 4-3/8 in H x 4-1/8 in W x 2-5/8 in D.
Mount it at the door opening, on a gate post or at a barrier lane where the station sees rain, dust and hose-down. It wires to the operator's open and close inputs plus common. There is no stop button on this model.
Features
- Open and Close push buttons
- Momentary, normally open contacts
- Die-cast aluminum enclosure
- NEMA 3R, 4 and 12 rated for exterior use
- Surface mount
- Contacts rated 6 A at 125/250 VAC
- UL listed
Before You Order
- No stop button. If your operator needs a stop input or a jumper is not allowed, order the 3BX (Open / Close / Stop).
- For a non-metallic housing, see the 2BXT. For heavy sun or driving rain, the 2BXC adds a protective cover.
- For corrosive or washdown areas, step up to a NEMA 4X station such as the 2B4X.
- Run 3 conductors: open, close and common.
- Need a single button? See the 1BX.
