LINEAR OSCO SWC-111 1HP SWING GATE OPERATOR

LINEAR OSCO SWC-111 1HP SWING GATE OPERATOR

  • Manufacturer: Linear - OSCO
  • Item Number:

  Add to cart to see price



LINEAR OSCO SWC-111 1HP SWING GATE OPERATOR

General

  • APeX Controller
  • Black polyethylene cover
  • Built-in MegaCode receiver
  • Gear reducer, size 60 (1/2 HP), size 70 (1 HP)
  • Quick disconnect crank assembly
  • Exterior reset button
  • Pad mount standard - optional post mount kit available
  • High starting torque - heavy duty PSC motor
  • ETL Listed for UL 325 (Class I-IV) for U.S. and Canada

Electrical

  • Integral entrapment sensing system with digital set point for quick accurate adjustment and enhanced safety
  • Continuous-tone entrapment alarm with reset button
  • LED diagnostic display for ease of setup and troubleshooting
  • Selectable pre-start and run alarm with provision for ADA compliant visual pre-start and run alarm
  • Regulated 24 Volt DC power available for access control accessories
  • Integrated maximum run and auto close timer (0-9 minutes)
  • Built-in networked dual gate capability using 3-wire shielded cable

Mechanical

  • Heavy-duty, zinc-plated, steel chassis
  • Lockable steel access door
  • Universal pad mount standard; optional post mount kit
Model HP Voltage & Phase Max Gate Length Max Gate Weight
SWC-111 1 115V 1P 17 ft 600 lbs

Schematic Diagram(s)


Order Replacement Parts
