Hysecurity SlideSmart HD 25

HySecurity ITEM: HD25
Hysecurity SlideSmart HD 25
Hysecurity SlideSmart HD 25
Hysecurity SlideSmart HD 25

Hysecurity SlideSmart HD 25

HySecurity ITEM: HD25
Regular price $3,602.00
  • Free shipping on most items over $200
  • We have 15+ years of industry experience
  • GSA, Net 30 and purchase orders available
Shipping calculated at checkout.



Heavy duty, 2,500 lb, 450 pull force, 1 ft/s
Heavy duty HD25 cycles up to 2,500 lb/50 ft gate (1,134 kg/15 m). Open/Close speed set independently, choose 0.75, 1 or 1.25 ft/s (23, 30 or 38 cm/s)* Robust zinc rich primer and black powder coated steel chassis and cover. Pad or post mount.

Includes one premium EMX IRB-MON photo eye and one 5-foot premium ASO edge sensor (and a pre-wired Hy2NC adapter).

Technical Specs

Duty Cycle Continuous
Travel Speed 0.75, 1 or 1.25 ft/s (23, 30 or 38 cm/s)** Open/Close speed set independently
Gate Length 50 ft (15 m)
Gate Capacity 2,500 lb (1,134 kg)
Operator HP 1/2 hp
Drive Type Electromechanical
Pull Force 400 lb
UPS Standard battery backup gate travel: Two 8Ah batteries. Up to 4,000 ft (1,219 m) after AC power loss. Field configurable to fail open or secure when batteries deplete. Extended battery backup gate travel: Two 50Ah batteries. Up to 25,000 ft (7,620 m) after AC power loss. Field configurable to fail open or secure when batteries deplete. Base riser required.
Voltage Input 115V or 208-230V, 60/50 Hz
Accessory Power 12VDC and 24VDC 1A each
Temperature Rating -13ºF to 158ºF (-25ºC to 70ºC) No heater necessary.
Communication USB, RS-232, RS-485. Ethernet/fiber using optional HyNet™ Gateway accessory
Relays Two configurable user relays: 30VDC, 3A solid state and 250VAC, 10A electromechanical; Optional Hy8Relay™ for 8 additional relay outputs
App Class Usage Class I, II, III, IV**
Finish Type Zinc plated chassis; molded polyethylene cover
Cycle Tested 500,000 cycles
Warranty 5 year (7 year single-family residential)
* *HySecurity manufacturers only reliable and powerful gate operators and provides an extra margin of power to be certain the gate works in adverse conditions. Some manufactures overstate the length and weight capacity of their operators, but HySecurity rates conservatively. Note that our pull force ratings are substantial and that extra margin of power is part of the HySecurity reputation for reliability.
** **Speed setting cannot be configured to exceed 1 ft/s for Class I and II usage. ***Not for residential use or applications intended to serve the general public.
*** †SlideSmart DC is exceptionally energy efficient, however actual battery backed up gate travel will depend on gate resistance to travel, cycle length, battery health, ambient temperature, accessories drawing battery power and frequency of gate cycles during power outage. †† Solar panels not supplied by HySecurity



Spec Sheet

Installation Manual

Installation Instructions Photo Eye

Installation Instructions Hy8Relay

Installation Instructions Heater

Installation Instructions base Riser Post Retro Fit
