AES EL00M-K e-Loop Mini Residential Wireless Loop Kit - Exit Only

AES ITEM: EL00M-K
Regular price $339.00
/
  • Current Trade Policy Costs Included In Price
  • In Cart Discounts Offered on Many Products
  • GSA, Net 30 and purchase orders available
Shipping calculated at checkout.

Description

The AES EL00M-K is the e-Loop Mini wireless vehicle detection kit for exit mode on residential gates. It pairs the EL00M sensor with an ETRANS50 e-Trans 50 transceiver. The sensor bolts to the surface in the middle of the driveway, and vehicles drive over it. When a vehicle is detected, the sensor signals the transceiver, and the transceiver relay opens the gate.

The sensor uses a 3-axis magnetometer and sends its trigger over 433.39 MHz with 128-bit AES encryption. Radio range to the transceiver is up to 150 ft (50 yd). Detection diameter is about 5 ft. It runs on 2 x 1.5 V AA lithium batteries with up to 3 years of battery life per AES. The housing is 4.7 x 4.7 x 1.2 in (120 x 120 x 30 mm) with a 5,500 lb (2,500 kg) static load rating. The ETRANS50 runs on 10-36 VDC per the AES data sheet and has one relay output (COM and N/O, 1 A) that wires to the open input of the gate operator.

What's Included

  • EL00M e-Loop Mini sensor (exit mode)
  • ETRANS50 e-Trans 50 transceiver
  • Base plate with M3 screws, 2 x dyna bolts and 4 x hex head bolts
  • 2 x AA 1.5 V lithium batteries

Before You Order

  • Complete kit. The EL00M listing is the sensor only, for adding a sensor to an existing e-Trans transceiver.
  • Exit mode only. It sends an open command when a vehicle passes; it does not hold the gate open while a vehicle sits on it.
  • The gate operator needs a dedicated open input with auto-close turned on.
  • AES rates the ETRANS50 for indoor use. Mount it inside the operator or in a weatherproof plastic box.
  • Use AA lithium batteries only. AES says not to use alkaline batteries.
  • Do not mount near high-voltage cables. They can affect detection.
  • Quick and easy installation.
  • Small compact design (120mm x 120mm x 30mm high) (4.7” x 1.1”).
  • Static load capacity 2500kg (5500 Ibs).
  • Uses standard 1.5V AA Lithium batteries (included).
  • Providing up to 3-4 years battery life.
  • High security 128-bit encryption.
  • Range up to 50 meters/yards.
    Detection Diameter approximately 5 feet
  • Frequency: 433.39 MHz
  • Modulation: FSK
  • Bitrate: 9.6 kbps
  • Bandwidth: 250 kHz
  • Antenna Type: PCB
  • Nominal Output Power: 10 dBm
  • Receive Sensitivity: -126.2 dBm
  • Security: 128-bit AES encryption
  • Spurious Emissions: 30 - 1000 MHz: < -56 dBm; 1 - 12.75 GHz: < -44 dBm; 1.8 - 1.9 GHz: < -56 dBm; 5.15 - 5.3 GHz: < -51 dBm
  • Power: 4 x 3.6 V 2700 mAh
  • Dimensions: 4.7 x 4.7 x 1.1 in
  • Weight: 1.1 lb
  • Environment: Designed for above ground mounting; IP68 ingress protection
  • Operating Temperature: -40 to 176°F
  • Standby Power: 14 µA
  • Activation Power: 50 mA
  • Transmitting Power: <10 mW
  • Safety: Tested to CE approval
  • EMC: EN 301 489-1 V2.2 (emissions to EN 55032, transmitter and receiver to EN 300 220-1 V3.1.1, immunity to EN 301 489-1)
  • Magnetometer Detection Areas: High: 0.6 m (0.6 yd); medium: 1 m (1 yd); low: 1.5 m (1.6 yd)
AES EL00M-K e-Loop Mini Residential Wireless Loop Kit - Exit Only - Specifications

Wireless vehicle detection for gate and barrier lanes where cutting a ground loop or trenching is not practical.

  • Free exit on swing and slide gates
  • Residential driveway gates
  • Gated community entrances
  • Business parks and shared access roads
  • Warehouse and service yard gates
  • Retrofits on finished driveways
