Reno A&E BX-LP Series Loop Detector

Reno A&E BX-LP Series Loop Detector

  • Manufacturer: Reno A&E
  • Item Number:

  • $104.00

Reno A&E BX-LP Series Loop Detector

The Model BX-LP is a single channel, low power vehicle detector with two relay outputs.

* Designed to minimize power consumption

* Eight external DIP switches

* Eight-position rotary switch

Perfect choice for all solar & battery powered installations.

* Extremely Low Power Consumption - 1.1 to 5.5 milliamps in No Detect state

* Delay Outputs:

o Output A:

+ Limited Presence

+ True Presence TM

o Output B:

+ Presence (Duplicates Output A)

+ Pulse-on-Entry

+ Pulse-on-Exit

* Delay Outputs A & B for two seconds

* Eight levels of sensitivity selectable from the front panel rotary switch

* External DIP switches

* Sensitivity Boost for applications where high-bed vehicles might be encountered

* Detect Memory feature maintains detection during momentary power interruptions of up to two seconds

* Fail LED indicates current loop failures or loop failures that have occurred.

* Four loop frequencies selectable from the front panel

* Super bright LED indicators for power, detect, and loop fail

* Selectable Fail-Safe or Fail-Secure operation during a loop fail condition

* 11-pin Amphenol connector

* Relay or Solid-State versions available

* 3.00" High x 1.75" Wide x 4.30" Deep

Model Number Information:

Model BX-LP-

= Blank: 12 VDC Input Power
: 24 VDC Input Power

= Blank: Relay Outputs
: Solid-State Outputs


We have 15 years experience working on these products in the field. Please contact us if we can be of any assistance!
